LGMA
Type Wheel Loader LGMA
| Specification | Value |
|---|---|
| Bucket Capacity | 3.0 m³ |
| Rated Payload | 5000 kg |
| Operating Weight | 17200±300 kg |
| Traction Force | 160±3 kN |
| Breakout Force | 185±3 kN |
| L×W×H | 8460×3000×3400 mm |
| Dumping Height | 3418 mm |
| Specification | Value |
|---|---|
| Bucket Capacity | 4.2 m³ |
| Rated Payload | 6500 kg |
| Operating Weight | 22100±300 kg |
| Traction Force | 200±3 kN |
| Breakout Force | 210±3 kN |
| L×W×H | 8805×3200×3540 mm |
| Specification | Value |
|---|---|
| Bucket Capacity | 5.2 m³ (7.0 m³ NGM) |
| Rated Payload | 7000 kg |
| Operating Weight | 23500 (24300)±300 kg |
| Traction Force | 200±3 kN |
| Breakout Force | 245±3 kN |
| L×W×H | 9200 (9430)×3400 (3480)×3460 mm |
Type Excavator LGMA
| Specification | Value |
|---|---|
| Operating Weight | 21,800 kg |
| Boom Length | 5675 mm |
| Arm Length | 2920 mm |
| Standard Bucket | 1.0 m³ |
| Max. Travel Speed | 3.1/5.3 km/h |
| Max. Swing Speed | 13.5 rpm |
| Grade Ability | 35° (70%) |
| Ground Pressure | 47.5 kPa |
| Max. Traction Force | 218 kN |
